Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm

  • Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm
  • Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm
Tempat asal Cina
Nama merek Aixton
Sertifikasi ISO9001,CE,FCC,ROHS
Nomor model AXT-MPO-8
Kuantitas min Order 50 pcs
Kemasan rincian polybag atau paket OEM
Waktu pengiriman 10-15 hari
Syarat-syarat pembayaran L/C,T/T,Western Union
Menyediakan kemampuan 100000pcs setiap bulan

Hubungi saya untuk sampel gratis dan kupon.

ada apa:0086 18588475571

Wechat wechat: 0086 18588475571

Skype: sales10@aixton.com

Jika Anda memiliki masalah, kami menyediakan bantuan online 24 jam.

x
Detail produk
Nama produk Kabel Batang Multimode （MTP） Modus Serat OM3 50/125μm
Jarak Ethernet 10G 300m pada 850nm Diameter Trunk 3.0mm-17.3mm
Panjang gelombang 850/1300nm Jenis Polandia UPC ke UPC
Konektor Standar IL ≤0.2dB Konektor Standar RL ≥30dB
Menyoroti

OM4 MTP/MPO Patch Cord Cable

,

10G OM4 Patch Cord Cable

,

12 Core OM4 Patch Cord Cable
Deskripsi Produk

Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm 0

                                                             Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm 1

OM3 24 Core MPO Male - LC Fiber 0.9mm Fan Out Patch Cables MTP Patch Cable Assemblies



MTP/MPO Trunk Cables

MTP/MPO trunk multifiber cable assemblies facilitate rapid deployment of high density backbone

cabling in data centers and other high fiber environments, reducing network installation or

reconfiguration time and cost. They are used to interconnect cassettes, panels or ruggedized

MTP/MPO fanouts, spanning MD A, HDA and EDA zones.



Standards Compliance

RoHS, CE (EN 50575 CPR), ISO9001 and WEEE Compliant

EIA/TIA, Telecocordia GR-326-CORE Standards

IEC61754-7

TIA 605-4 (FOCIS 5)

YD/T1272.5



Features

  1. 100% pre-terminated and tested in factory to ensure transfer performance
  2. Rapid configuration and networking, reduce installation time
  3. Supports 40G and 100G network applications
  4. Jacket material: LSZH, OFNR, OFNP available
  5. Supports up to 12F, 24F, 48F, 72F, 96F, 144F, customized products are available



Model SM MM
Connector A:MPO/MTP
Connector Fiber Count 8,12,24,48 Core
Polish PC,APC PC
Insertion Loss Standard ≤0.70dB ≤0.50dB
Elite Low Loss ≤0.35dB ≤0.30dB
Return Loss PC≥50dB,APC≥60dB ≥30dB
Durability(500 Matings) ≤0.2dB
Test Wavelength 1310/1550nm 850/1300nm
Connector B:LC,LC Uniboot,SC,FC,ST
Polish PC,APC PC
Insertion Loss ≤0.2dB ≤0.2dB
Return Loss PC≥50dB,APC≥60dB ≥35dB
Durability(500 Matings) ≤0.2dB

Product Details

Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm 2

Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm 3

Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm 4

Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm 5





FAQ

Vietnam OM4 MTP/MPO 8 12 16 24 Core Fiber Single Mode Optic Patch Cord Cable for 10G Ethernet Distance of 300m at 850nm 6



Q1:What are the advantages of your price?

A1: We have our own factory, professioanl machinery equipment . We can meet the price advantage of

products with the same quality parameters, and we promise to achieve a price of 1%-10% lower than

that of our peers.

Q2: What is your quality advantage?

A2: We strictly according to the ISO9001 quality management system, insisting "Enough Cores,

Enough Meters, High Quality, High Performance". Providing our customers with higher quality

products and services.

Q3. Do you support customized brands?

A3: Yes! The professional OEM services will be welcomed to us. Our factory accepts to make the

logo free for bulk orders.

Q4: What are the benefits of working with you?

A4: New customers can enjoy AIXTON’s stock and annual year-end dividends, and support

long-term cooperative customers to upgrade to global agents and enjoy more discounted prices.
